3-Phase 240V Charger

Lithium-ion Charger

Battery Voltage: 24V, 36V, 48V, 72V, 80V, 96V
Input Voltage: 3-Phase 240V / 3-Phase 208V
Charging Connector: REMA320
Certification: cTUVus
3-Phase 208V/240V Lithium-ion Charger Details

ULBS’3-Phase 208V/240V Lithium-ion Charger provides a safe, reliable, and fast charging solution for ULBS’ upgraded power solutions. It uses the CAN-BUS to communicate with the Lithium Iron Phosphate (LiFePO4) battery pack to automatically adjust the charging current for best performance based on the environmental and working conditions. This charger has an export function that allows end-users to record and save the charging date through the integrated SD port. Additionally, it also features fast voltage dropping protection to avoid charger connector damage.

ULBS 3-Phase 208V/240V Charger Feature:
-Simple & User-Friendly Interface
-Safe Operating Platform with UL Certification
-Multi-level Protection for Both the Battery & Charger
-Lightweight & Compact
-Rapid Charge with ULBS Lithium-Ion Battery Pack

Return on Investment
Rapid Charging
Opportunity Charging
Safe and Reliable
3-Phase 480V Lithium-ion Charger Specifications
Model FST-Li-48V200A-220V3P FST-Li-80V200A-220V3P
Stand FST-S-001 FST-S-001
Input Voltage AC208V 3-Phase Four-Wire system
AC240V 3-Phase Four-Wire system
AC208V 3-Phase Four-Wire system
AC240V 3-Phase Four-Wire system
Applicable Voltage 24V, 36V, 48V 72V, 80V, 96V
Input Current <38A <64A
Breaker Specifications 40A 70A
Maximum Voltage DC60V DC100V
Maximum Output Current 200A 200A
Maximum Power 13kW 22kW
Charging Connector REMA320 REMA320
Communication CANBUS CANBUS
Conversion Efficiency ≥93% ≥93%



ULBS Lithium-ion Charger Spec Sheet

ULBS Lithium-ion Charger Spec Sheet
